Rugged Mobile Computer
CK67 mobile computers, built on the Mobility Edge™ platform, are ultra-rugged, all-purpose productivity devices ensuring reliable performance, ergonomic design, 5G and Wi-Fi 6E data connectivity for users in Distribution Centers and Warehouses.
Industry Use:
- Distribution Center
- Warehouse
- Yards
CK67 mobile computers, built on the Mobility Edge™ platform, are ultra-rugged, all-purpose productivity devices ensuring reliable performance, the latest in ergonomic design, 5G and Wi-Fi 6E data connectivity for front-line workers in Distribution Centers and Warehouses.
Overview
The CK67 is built on the Mobility Edge™ platform, a durable, stable, secure foundation for effective, long-lasting solutions. The CK67 delivers the lifecycle, security and durability required by serious businesses. The CK67 harnesses the latest Qualcomm® QCM4490 processor and memory technology for high performance with guaranteed support through Android 18.
Connectivity
The CK67 has the latest 5G and Wi-Fi 6E chipset technology to stay connected in both indoor and outdoor environments. With the latest 5G release, CK67 offers the highest bandwidth, versatility and lowest latency available for warehouse and DC workers to always stay connected. Whether you are on a private 5G or CBRS network, or a Wi-Fi 6E environment, your workers can continue their workflows with the most reliable uptimeEach CK67 comes with a standard 2nd BLE and a USB-C port for alternate charging options or data transfer.
Durable and Reliable
The CK67 is designed to endure the most challenging environments in warehouses and DCs. Warehouses are as busy as ever and operators need to keep their workflows running efficiently with maximum uptime. Users in warehouses can rely on the CK67, withstanding up to 8ft drops across operating temperatures and 4,000 1.0m tumbles. Users can be confident with the intense durability testing the CK67 undergoes before release, that it will solidify and keep operations and is the ultimate long-term investment
Focus on Ergonomics
The CK67 comes in an updated form factor, with a sleek modern design, a larger screen, and a more ergonomic scan handle to satisfy most users and applications. The keypads have updated buttons for responsiveness and better spacing, for an enhanced user experience. And the balance of the CK67 has been optimized to feel light in the hands of the users. The CK67 is a significant advance in a mobility device to enhance the user satisfaction.
Specifications
FEATURES
Camera
- 8MP, 13MP
Application
- Distribution Center
- Warehouse
- Yards
Camera Position
- Front and Rear
DIMENSIONS
Overall Dimensions
- 22.7cm x 8.3cm x 4.2cm; 8.3in x 3.3in x 1.6in
- Weight: 508g
SCANNING SPECIFICATIONS
Decode Capability
- Honeywell FlexRange™
- Standard Range Engine (1D/2D barcode symbologies)
- Yes
NETWORK
Computer Wireless Communication
- Yes
Bluetooth Specifications
- 5.3
WWAN Specifications
- 4X4 MIMO supported: 5G: n2, n7, n25, n30, n38, n41, n48, n66, n77, n78, n79; 4G : B2, B4, B7, B25, B30, B38, B41, B42, B43, B48, B66
- 5G FR1: Bands 1, 2, 3, 5, 7, 8, 12, 13, 14, 20, 25, 26, 28, 29, 30, 38, 40, 41, 48, 66, 71, 77, 78, 79
- 5G NSA – DL: ~2500 Mbps, UL: ~1050 Mbps
- 5G SA – DL: ~2300 Mbps, UL: ~1050 Mbps
- AT&T FirstNet Compliant
- Global bands support, device certified with GCF-PTCRP, ATT, TMO, VZW
- LTE Advanced Support: Up to 390 Mbps CAT13 LTE downlink. Up to 75 Mbps CAT5 LTE uplink 4G-LTE DL Cat-18, ~800 Mbps; 4G-LTE UL Cat-18, ~200 Mbps
- LTE: Bands 1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28, 29, 30, 38, 39, 40, 41, 42, 43, 66, 71
- WWAN Radio
WLAN Specifications
- 5GHz: 802.1/n/ac/ax- 20MHz, 40MHz, 80MHz, 160MHz upto 2402Mbps; 802.11ax20MHz, 40Mhz, 80MHz, 160Mhz-upto 2402 Mbps
- Data Rates: 2.4GHz:802.11b/g/ ax- 20MHz -upto 286.8 Mbps
- Dual Band Simultaneous(DBS)
- IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v/w/mc/ax, 2x2 MU-MIMO
- IPv4
- IPv6
- Supported EAP: TLS, PEAP, TTLS, PWD, LEAP, CCX compatible
- Triband (2.4GHz, 5GHz, 6GHz)
- WLAN Security: OPEN, WEP, WPA/WPA2/WPA3 (Personal and Enterprise)
- Wi-Fi certified
- Wi-Fi™ 6E (801.11ax)
- Wi-Fi™ 6E certified
GPS Specifications
- Yes
SOFTWARE & FIRMWARE
Operating System
- Released with Android 14 and guaranteed through Android 18
Platform
- Mobility Edge
MEMORY & DATA
Memory
- 8GB DDR4x RAM, 128GB UFS Flash
- User-accessible microSD card up to 2TB (SDXC/SDHC/SDIO – compliant)
HARDWARE
Display Resolution
- 800 x 480
Display Size
- 10.9cm (4.3in)
Processor
- QCM4490
- Qualcomm QCS4490/QCM4490 octa-core 2.4GHz
Keyboard
- 51 or 53-key alpha numeric, 38 or 42-key numeric function, or 30- key large numeric keypads, plus two programmable side buttons
- Backlight LED
- Yes
Network
- Wi-Fi GE
ELECTRICAL
Battery Capacity
- 7000mAh
Battery Type
- Lithium Ion
- Smart battery with integrated diagnostic tools
ENVIRONMENTAL
Storage Temperature Range
- -30°C to +70°C (-22°F to +158°F)
Operating Temperature
- -20°C to +50°C (-4°F to +122°F)
Cold Storage
- Yes
STANDARDS & APPROVALS
Tumble Specifications
- Exceeds 4,000 tumbles at 1m (3.28ft) per IEC 60068-2-32 specification
Drop Specifications
- 10ft drop
- Multiple 2.4m (8ft) drops to concrete booted per MIL-STD-810H at -10°C to 50°C (14°F to 122°F)
Protection Ratings
- Certified for IP65 & IP68
SERVICE TERMS
Warranty Duration
- One year factory warranty
OTHER
Scan Distance
- Long Range (0-20m)
- Mid Range (0-5m)
- Standard Range (0-1m)
Connectivity
- Wi-Fi & Cellular
Environment
- Standard
Durability
- 4000 1.0m tumbles
Keypad
- Alphanumeric
- Numeric
